Pressure: 0.8~1.2MPa
PH range: 5.5 ~ 8.5
Applicable temperature: 5~40°C
Feed Water TDS: ≤600PPM
Desalination rate: ≥98%
Recovery rate: ≥30%
Organic matter removal rate: ≥99%
Bacterial removalrate: ≥99.9%
Customizable product accessories
Ro Membrance
Model: ULP31-4040Flow rate: ≥7.2m3/h(25°C)Desalination rate %:99.4%Max Inlet Water Temperature: 45 °CMax Working Pressure:600pai(4.14Mpa)Effective membrane area ft2(m2) :85(7.9)
Operation: automatic control, automatic flushMembrane material: aromatic polyamide composite membraneMembrane housing material: SUS 304
PP
Function： filtration
Shell Material: 20'blue housing
Cartridge material:
Spray-fusing polypropylene
5um 20'
Cartridge Qty: 6pcs
High-pressure pump
Model:CVF2-13T 1.1kw
Material: SUS304
Flow: 3.2m3/h
Lift: 60m
| Name |
Capacity |
Size(cm) |
Weight(kg) |
Activited carbon
(25kg/bag) |
Sand
(40kg/bag) |
Resin
(20kg/bag) |
| GY250-12N4040-A02 |
1500GPD |
145x68x165 |
130 |
1 |
1 |
0 |
| GY250-12N4040-A02 |
1500GPD |
110x68x162 |
100 |
1 |
1 |
2 |
| GY500-12N4040-A02 |
3000GPD |
145x68x165 |
150 |
1 |
1 |
0 |
| GY500-12N4040-A02 |
3000GPD |
64X68X140 |
60 |
0 |
0 |
0 |
Processing Type
Reverse Osmosis
productivity
250L/Hour
core components
Pump
Power(W)
1 kW, 2 kW
Voltage
220 V, 380 V, 110 V
warranty
1 Year
machinery test report
Provided
video outgoing-inspection
Provided
weight (kg)
70
place of origin
China
brand name
OEM
Product name
hot sales water treatment plant ro industrial
Material
stainless steel frame
Application
Water purification
Type
Pure Water Treatment System
Usage
Pure Water Process
Capacity
250LPH/500LPH
Voltage
110v/220v/380v
Control
Electronic control
Feature
Eco-Friendly Easy Operation
customize
OEM ODM
Packaging and delivery
Selling Units
Single item
Single package size
64X68X140 cm
Single gross weight
75.000 kg
